| Image Sensor1/2.7" Progressive Scan CMOS |
Max resolution2560*1440 |
Main Stream50 Hz: 25fps@(2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30fps@(2560 × 1440, 1920 × 1080, 1280 × 720) |
Substream50 Hz: 25 fps@(704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps@(704 × 576, 640 × 480, 352 × 288) |
Video CompressionMain stream: H.265/H.264
Sub-stream: H.265/H.264 |
Video Bitrate256 Kbps - 8Mbps |
| Audio CompressionG.711ulaw/G.711alaw/AAC |
Built-in MicrophoneYes, record with audio |
| Built-in SpeakerYes, max. sound pressure level: 10 cm: 95 dB |
Lens2.8 mm |
| Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
Angle of ViewHorizontal FOV 113.31°, vertical FOV 59.85°, diagonal FOV 136.26° |
| Supplement Light TypeSmart Dual-Light, IR, White Light |
Supplement Light RangeUp to 30 m |
| Smart DetectionOn/off duty detection and alarm |
Temperature Sensing ModeThermistor |
Alarm Indicator Light4-color indicator light
Red/Blue: alarm (red or blue mode is optional)
Yellow: fault
Green: normal |
High Temperature AlarmSupported |
| Measurement Range32℉ ~ 248℉ |
Temperature Precision±37.4°F (In a constant temperature environment without wind, power on for 1 hour) |
| Audio AlarmBeeping alarm |
Image EnhancementBLC, HLC, 3D DNR |
| Wide Dynamic Range120 dB WDR |
ProtocolsTCP/IP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IPv4, UDP |
| Region of Interest (ROI)4 fixed region for main stream |
Privacy Mask4 programmable polygon privacy masks |
| General FunctionMirror, password protection, remote access |
Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Alarm Interface1 way alarm input ( Alarm in), 2 way alarm output ( Alarm out) |
Auxiliary Power InterfaceSupports DC 12V output, power 1W |
| HousingPlastic |
ColorWhite |
